Lucite Block Acrylic

Benefits of Lucite Block Acrylic

• Chunky letter designs
• Optimized light transmission to maximize economic and environmental benefits of LED technology
• Can be used with white or colored LEDs
• Easy to fabricate
• Excellent quality
• Consistency of color & high gloss surface quality
• Robust strength
• High maximum service temperature
• Constant transmission colors are constant in the manufactured thicknesses
• Light can be directed out of the front of the panel, sides, or even the back

This product allows you to produce your sign almost entirely with your router.

The sheets come in one size – 1.18″ x 59″ x 78″

Fabrication tip

We normally recommend that any channels or holes that are drilled into the sheet are no more than 50% of the block thickness so 12-15mm (.472-.591″) in this case, however, most channels are about 6-8mm (.236-.315″).

There are two main styles of block acrylic fabrication

Method 1

• Shallow “channels” are routed out of the rear of the letters. LEDs are embedded into the channel and sealed
• LED units sealed in place with acrylic cement
• Good weather resistance
• Heat management critical to system success (otherwise LEDs will get too hot and burn out)

Method 2

• The center of the letter is completely routed out to create a void and LEDs are attached to a metal back plate.
• Variation in wall thickness after routing will result in uneven light output
• Metal plate assists with thermal management of LEDs
